1Hz~50MHz Crystal Frequency Meter Tester Measurement LED 5-Digits DIY Kit

- Specification: - Welding installation considerations, these steps: - The components are welded on the back of the board (including good resistance capacitance microcontroller screen printing side), from low to high, the first principle, namely low welding components, such as crystal, capacitor, resistor, diode. - The welding microcontroller header, and then welding, triode, knob, a power outlet. - The back with a side cutter to short the pins as far as possible - Debugging steps: - After completion of welding IC PIC16F628 microcontroller, note the direction of IC, the insert can damage the chip! - Check the IC or against, such anti take timely correction. - After the check, the electricity, the fourth digital tube display 0. said the installation was successful! - Using the step of: - Before measuring signal, please switch J1 jumper cap. blue terminals for the IN for signal input, GND GND for signal input signal amplitude does not exceed 30 V, otherwise the frequency meter damage. - Before measuring crystal please switch the J1 jumper cap in JP1 insert 4 m to 40 m crystals can measure the crystal frequency - Note: This is unassembled DIY Kits Package Includes: 1 Piece Frequency Meter DIY kit Giá sản phẩm trên Tiki đã bao gồm thuế theo luật hiện hành. Bên cạnh đó, tuỳ vào loại sản phẩm, hình thức và địa chỉ giao hàng mà có thể phát sinh thêm chi phí khác như phí vận chuyển, phụ phí hàng cồng kềnh, thuế nhập khẩu (đối với đơn hàng giao từ nước ngoài có giá trị trên 1 triệu đồng).....
