Bộ Công Tắc Điều Khiển Từ Xa Cho Xe Hơi 2ch Ac 220v

Features: Jog mode: Press the remote control relay to close and release the remote control relay to disconnect. Jog learning method: press the learning button once, the LED indicator flashes quickly 3 times and then goes out, enter the learning state, press any button of the remote control, the LED indicator flashes quickly 3 times and then goes out, then press the remote control button 2, the LED indicator flashes 3 times and then lights up continuously, indicating that the code is successful. (PS. Because it is 2 roads, you need to learn 2 buttons) Self-locking mode: Press the remote control relay to pull in, and press the remote control again to disconnect the relay. Self-locking learning method: press the code button twice in succession, the LED indicator flashes quickly 3 times and then goes out, enters the learning state, press any button of the remote control, the LED indicator flashes 3 times and then goes out, then press the remote control. Button 2, the LED indicator flashes 3 times and then lights up continuously, indicating that the code is successful. Interlock mode: Press the remote control A button, the relay is closed, press the remote control B button to disconnect. Interlocking learning method: press the code button 3 times in succession, the LED indicator flashes quickly 3 times and then goes out, enters the learning state, press any button of the remote control, the LED indicator flashes 3 times and then goes out, then press the remote control. Button 2, the LED indicator flashes 3 times and then lights up continuously, indicating that the code is successful. Clearing function: Press the code button 8 times in succession. After the LED indicator flashes 4 times and then it is always on, the clear code is completed, and all the remote control key codes that have been learned before are cleared. Specifications: Type: Remote Control Switch Kit Material: Plastic, Electronic Components Color: As Picture Controller Box Size(L*W*H): About 74x55x25mm Remote Control Battery: 2x Button Battery(included) Working Voltage: AC85-250V Working Frequency: 433.92MHZ Quiescent Current: 8.5mA Load Power: 2200W Receiving Sensitivity: -105dBM Working Mode: Jog, Self-Locking, Interlock Output Signal: Can output 2 way switch signal or 2 way AC220V voltage signal Coding Method: Learning Code Modulation Method: ASK Working Temperature: -10~+70 ° C Remote Control Distance: 100 meters Total Load Power: 1100W per way Package Included: 1pc x Controller 1pc x Controller Box 5pcs x Remote Control Note: 1. Due to the light and screen difference, the item's color may be slightly different from the pictures. 2. Please allow 0.5-2 cm differences due to manual measurement. Giá sản phẩm trên Tiki đã bao gồm thuế theo luật hiện hành. Bên cạnh đó, tuỳ vào loại sản phẩm, hình thức và địa chỉ giao hàng mà có thể phát sinh thêm chi phí khác như phí vận chuyển, phụ phí hàng cồng kềnh, thuế nhập khẩu (đối với đơn hàng giao từ nước ngoài có giá trị trên 1 triệu đồng).....
