Bộ Cảm Biến Dao Động P6060 60mhz X10 X1 Chuyên Dụng

P6060 60MHZ X10 X1 Probe Oscilloscope Probe Kit Oscilloprobe Oscilloscope Sonde This oscilloscope probe is top quality of oscilloprobes and very practical for testing the oscilloscope. It is provided with several accessories designed to make probing and measurement simpler. Features: Use the slide switch to set probe attenuation ratio. Use the alligator clip to attach the probe to a ground reference. Use the adjustment tool for probe compensation adjustments. Use locating sleeve could ensure the stability and reliability of the tip exposed to the test point. Spare maker rings attach the matched color rings onto the probe cable and shaft to identify different channels. Considerate design and efficient assist tools. Specifications: Bandwidth: 60MHz Rish Time: 5.8ns Attenuation Ratio: 1X & 10X Input Resistance: 1X: 1MΩ±2% 10X: 10MΩ±2% Input Capacitance: 1X: 70pF～120pF 10X: 14pF～18pF Maximum Input: 1X: 200 Working Voltage (Vp-p) 10X: 600 Working Voltage (Vp-p) Compensation Range: 15～45pF Operation Environment: 0～50℃, 0～80%RH Storage Environment: -20～60℃, 0～90%RH Color: Grey + Black Material: PVC, Copper Pipe Length of the Item: Approx. 123cm / 48.4in Item Weight: 98.1 / 3.4oz Package Size: Approx. 22 * 14 * 2cm / 8.7 * 5.5 * 0.8in Package Weight: 128g / 4.5oz Package List: 2 * Probe Wire 2 * Retractable Hook Tip 1 * Adjustment Tool 2 * Locating Sleeve 6 * Maker Rings 2 * Ground Lead Giá sản phẩm trên Tiki đã bao gồm thuế theo luật hiện hành. Bên cạnh đó, tuỳ vào loại sản phẩm, hình thức và địa chỉ giao hàng mà có thể phát sinh thêm chi phí khác như phí vận chuyển, phụ phí hàng cồng kềnh, thuế nhập khẩu (đối với đơn hàng giao từ nước ngoài có giá trị trên 1 triệu đồng).....
