Màn hình TFT 4.3 Inch NX4827P043_011C_Y cảm biến điện dung của Nextion có vỏ hộp
Thông tin sản phẩm. Hardware Features 4.3” LCD-TFT HMI display module 480 x 272 screen resolution RGB 65K true-to-life colours Capacitive or Resistive touch panel 300 nit Brightness Onboard 200MHz MCU 512 KB of SRAM 128 MB of Flash memory 1024 Byte EEPROM XH2.54 4 Pi
dientuxanh.vn
@dientuxanh.vnĐánh giá
Theo Dõi
Nhận xét
Hạn bảo hành
1 tháng
Thông tin sản phẩm. Hardware Features 4.3” LCD-TFT HMI display module 480 x 272 screen resolution RGB 65K true-to-life colours Capacitive or Resistive touch panel 300 nit Brightness Onboard 200MHz MCU 512 KB of SRAM 128 MB of Flash memory 1024 Byte EEPROM XH2.54 4 Pins (+5V, TX, RX, GND) TTL serial interface 1.25T-2-2A Audio port for external speaker connection 8 Digital extended GPIO (IO0-IO7 support input, output and component binding event, IO6-IO7 support PWM) Built-in RTC support Nextion Editor Nextion Editor overview Nextion Editor is a free human-machine interface (HMI) GUI development software for Nextion Basic Series, Enhanced Series, and Intelligent Series. The software offers an easy way to create an intuitive and superb touch user interface even for beginners. Add a static picture as a background, define functions by components, you can make a simple GUI in minutes. The easy Drag-and-Drop components and simple ASCII text-based instructions will dramatically reduce your HMI project development workloads and develop projects rapidly in a cost-effective way. The Nextion product is the best balance HMI solution between cost and benefit with a low and decreased learning curve. https://nextion.tech/datasheets/nx4827p043-011c-y/
