Mô đun định vị vệ tinh hai chế độ GPS+BDS ATGM336H
ATGM336H Module GPS Beidou dual mode module flight control with EEPROM The ATGM336H-5N series module is a general term for the small-size high-performance BDS/GNSS constellation positioning navigation module series. The series of modules are based on the four
meltsee.vn
@meltsee.vnĐánh giá
Theo Dõi
Nhận xét
Thương Hiệu
No brand
ATGM336H Module GPS Beidou dual mode module flight control with EEPROM The ATGM336H-5N series module is a general term for the small-size high-performance BDS/GNSS constellation positioning navigation module series. The series of modules are based on the fourth generation of low-power GNSS SOC single chip - AT6558, supporting a variety of satellite navigation systems, including China's BDS (Beidou satellite navigation system), the United States' GPS, Russia's GLONASS, the EU's GALILEO, Japan's QZSS and satellite augmentation system SBAS (WAAS, EGNOS, GAGAN, MSAS). The AT6558 is a true 6-in-1 multi-mode satellite navigation positioning chip that includes 32 tracking channels that can simultaneously receive GNSS signals from six satellite navigation systems and enable joint positioning, navigation and timing. ATGM336H-5N series modules have the advantages of high sensitivity, low power consumption and low cost. They are suitable for in-vehicle navigation, handheld positioning and wearable devices, and can directly replace Ublox MAX series modules. Output protocol: Output protocol: The ATGM332D-5N series module uses the UART as the main output channel and outputs according to the protocol format of NMEA0183. Performance: Excellent positioning and navigation function, support single system positioning of BDS/GPS/GLONASS satellite navigation system, and multi-system joint positioning of any combination, and support QZSS and SBAS system Support A-GNSS Cold start capture sensitivity: -148dBm Tracking sensitivity: -162dBm Positioning accuracy: 2.5 meters (CEP50, open space) First positioning time: 32 seconds Low power consumption: continuous operation <25mA (3.3V) Built-in antenna detection and antenna short circuit protection #GPS#BDS#ATGM336H
